　　【MOVIDRIVE?和MOVIDRIVE?compact變頻器】

　　設計 ——SEW MOVIDRIVE?和MOVIDRIVE? compact變頻器功率范圍已達到132kW，在動態響應和控制精度上達到更高的需求。

　　變頻器安裝在開關柜內。

　　變頻器可以并排無間隙安裝，結構緊湊，充分利用空間。?

　　VFC ——VFC設計(電壓矢量控制)可以帶或不帶速度反饋，能夠達到異步驅動的高控制精度。?

　　CFC—— CFC控制(電流矢量控制)的MOVIDRIVE?變頻器可以滿足更高的控制精度和動態響應，使用MOVIDRIVE?變頻器的CFC控制可以使異步驅動達到伺服驅動的效果。?

　　四象限運行 ——在MOVIDRIVE?和MOVDRIVE? compact變頻器的標準設計中集成了制動斬波器。變頻器配合適當?shù)闹苿?dòng)電阻和電源能量回饋裝置可以實現四象限運行。?

　　EMC ——只要按照EMC安裝要求，這類變頻器滿足EN 50 081(抗輻射干擾等級A或B)和EN 50 082EMC標準。所以需要執行EMC安裝準則。?

　　操作和信息—— 友好的PC操作方式和信息理念提供了快捷的系統啟動和便捷的服務。?

　　【SEW變頻器MD_特性】

　　·輸入端子由光電耦合器隔離保護。

　　·高的靜態轉子扭矩和運行扭矩，由-VFC控制在0.5Hz以上，至少150％額定扭矩。-CFC控制，在整個調速范圍內，至少160％的額定扭矩。

　　·工廠設定可以適用于適配的SEW電機或自動實現最優化控制。

　　·MOVITOOLS ?一用于界面(win95/98/NT)，方便的參數設定、操作，過程數據顯示。操作系統的應用軟件。

　　·可適用的功能如:提升功能。

　　· IPOS位控功能為標準配置，無需附件。?

　　·變頻器和電機的全方位保護，可以防止短路、過載、接地及過熱。

　　·另外附加的功能如fieldbus接口，同步運行控制和絕對值編碼器接口(不適用于MOVIDRIVE? compact)。

　　· MOVDRIVE? compact有內置PROFIBUS接口的版本。

　　·具有北美CUL認證。?

　　MOVIDRIVE? 【MDF型】功能 不加編碼器變頻器通過 VFC控制異步電機?

　　電源電壓 :3×380...500V 、3×230V?

　　推薦電機功率 :1.5...132 kW 、1.5...30 kW?

　　額定電流 :4.0...250A 、7.3...95A?

　　MOVIDRIVE? 【MDV型】 功能VFC控制或選擇CFC控制實現異步伺服運行?

　　電源電壓 :3×380...500V、 3×230V?

　　推薦電機功率: 1.5...75/132 kW 、 1.5...30 kW?

　　額定電流 :4.0...250A 、7.3...95A?

　　MOVIDRIVE?【MDS型】 功能 變頻器用于高動態響應的同步伺服電機?

　　電源電壓 3×380... 500 V?

　　額定電流 4.0... 250 A?

　　MOVIDRIVE?【MDR型】 功能 再生功率模塊

　　電源電壓 3×380... 500 V?

　　推薦電機功率 37... 75/90 kW?

　　【MOVITRAC LT系列變頻器】

　　設計 SEW MOVITRAC LT 變頻器功率范圍達到 160KW ，適用于幾乎所有的開環驅動應用，可對 SEW 和非 SEW 交流減速電機進行變頻調速。?

　　操作及顯示 ——完備的功能、簡便的操作，出廠值適用于大多數應用場合?？赏ㄟ^紅外接口進行快速、準確的參數設定及操作。?

　　EMC SEW MOVITRAC LT 變頻器是按高標準電磁要求設計的，滿足 EN610004(A 級 )EMC 標準。?

　　特性 ·產品系列

　　-110-115V ， 1/2 ． 1 1/2 HP

　　-220-240V ， 0.37KW-90KW( 單相或三相 )

　　-380-480V ， 0.75KW-160KW

　　-480-525V ， 18.5-160KW

　　·單一驅動器的觀念降低了庫存，培訓及技術支持等費用

　　·外型緊湊

　　·可以應用于惡劣的工業場合，環境溫度等級50 度

　　·機械和電氣安裝簡單

　　·操作簡單，性能優越，易于應用

　　·初始化簡單，出廠設定值幾乎適用于大多數應用。只有14個基本參數進行

　　調整( 最多40個)

　　·內置制動斬波器 ( 非 S1 工作制 ) 可選

　　·內置的 RFI 濾波器和進線扼流圈 (s4 ， 5&6)

　　·電機電流和轉速指示

　　· 32KHZ 開關頻率，電機低噪聲運行

　　·通過參數 P-00 進行故障診斷

　　· 150 ％過載運行 60S(175 ％過載運行 2S)

　　·單相變頻器高功率 ( 到 45KW)

　　·光纖通訊?

　　MOVITRAC LTS標準型?

　　功率 0.75...160 KW?

　　推薦電機功率 O.37 KW...160 KW?

　　電源電壓?

　　3×220...240 V?

　　3×380...480 V?

　　MOVITRAC LTP矢量型?

　　功率 0.75...160 KW?

　　推薦電機功率 O.37 KW...160 KW?

　　電源電壓?

　　0.75...160 KW V?

　　3×380...480 V?

　　MOVITRAC LTE型?

　　功率 0.37...4.0 KW?

　　推薦電機功率 O.37 KW...4.0 KW?

　　電源電壓?

　　3×220...240 V (O.37...2.2 KW)?

　　3×380...480 V (O.75...4.0 KW)

　　故障代碼 故障現象/類型 故障原因 解決對策 01 Over-current ? Short circuit on output ? Output switching ? Motor too large ? Defective output stage ? Ramp limit (P138) switched off ? Rectify the short circuit ? Only switch when output stage inhibited ? Connect a smaller motor ? Call SEW Service for advice if the fault still cannot be reset ? Ramp limit (P138 = YES) 03 Ground fault ? Ground fault on motor ? Ground fault on inverter ? Ground fault in the motor lead ? Over-current (see F-01) ? Replace the motor ? Replace the MOVITRAC? 07 ? Rectify the ground fault ? See F-01 04 Brake chopper ? Regenerative power excessive ? Braking resistor circuit interrupted ? Short circuit in braking resistor circuit ? Excessively high braking resistance ? Brake chopper defective ? Ground fault ? Extend deceleration ramps ? Check connecting harness for braking resistor ? Rectify the short circuit ? Check technical data of braking resistor ? Replace the MOVITRAC? 07 ? Rectify the ground fault 06 Supply system phase failure (only with three-phase inverter) Phase fault Check supply system lead 07 DC-link overvoltage ? DC link voltage too high ? Ground fault ? Extend deceleration ramps ? Check connecting harness for braking resistor ? Check technical data of braking resistor ? Rectify the ground fault 08 Speed monitoring Current controller is operating at the setting limit due to: ? mechanical overload ? phase failure in supply system ? phase failure in motor ? Reduce load ? Increase delay time setting P501 ? Check current limitation ? Extend deceleration ramps ? Check supply system phases ? Check motor feeder and motor Maximum speed for VFC operating mode exceeded ? Reduce load ? Increase delay time setting P501 ? Check current limitation ? Extend deceleration ramps ? Check supply system phases ? Check motor feeder and motor Maximum speed for VFC operating mode exceeded ? Reduce maximum speed 10 ILLOP ? Incorrect command during running of program ? Incorrect conditions during running of program ? Function not in inverter / not implemented ? Check program ? Check program structure ? Use another function 11 Overtemperature Thermal overload of inverter ? Reduce load and/or ensure adequate cooling ? If the braking resistor is integrated in the heat sink: Mount the braking resistor externally 17-24 System fault Inverter electronics disrupted, possibly due to effect of EMC Check ground connections and shields; improve them if necessary. Contact SEW Service for advice if this reoccurs. 25 EEPROM Fault when accessing EEPROM Call up default setting, perform reset and set parameters again. Contact SEW Service for advice if this reoccurs. 26 External terminal Read in external fault signal via programmable input Eliminate specific cause of fault; reprogram terminal if appropriate. 31 TF sensor ? Motor too hot, TF sensor has tripped ? TF sensor of motor not connected or not connected properly ? Connection of MOVITRAC? 07 and TF interrupted on motor ? Let motor cool down and reset fault ? Check connections/links between MOVITRAC? 07 and TF 32 Index overrun Basic programming rules violated causing internal stack overflow Check and correct user program 34 Ramp timeout The inverter signals F34 if you revoke the enable and the drive exceeds the rapid stop ramp time t13 by a certain time. Extend the rapid stop ramp time 37 Watchdog timer Fault in system software sequence Check ground connections and shields; improve them if necessary. Contact SEW Service for advice if this reoccurs. 38 System software System fault Check ground connections and shields; improve them if necessary. Contact SEW Service for advice if this reoccurs. 43 RS-485 timeout Communication between inverter and PC interrupted Check connection between inverter and PC. 44 Unit utilization Unit utilization (Ixt value) excessive ? Reduce power output ? Extend ramps ? If these points are not possible: Use a larger inverter 45 Initialization Error during initialization Contact SEW Service for advice. 47 System bus timeout Fault during communication via system bus Check system bus connection. 故障代碼 故障現象/類型 故障原因 解決對策 77 Control word An external control has attempted to set an invalid automatic mode ? Check serial connection to external control ? Check write values of external control 81 Start condition Only in "VFC hoist" operating mode: The inverter could not inject the required amount of current into the motor during the pre-magnetization time: ? Motor rated power too small in relation to inverter rated power ? Motor cable cross section too small ? Check connection between inverter and motor ? Check startup data and repeat startup if necessary 82 Output open Only in "VFC hoist" operating mode: ? Two or all output phases interrupted ? Motor rated power too small in relation to inverter rated power Check connection between inverter and PC. 94 EEPROM checksum EEPROM defective Contact SEW Service for advice. 97 Copy fault ? Parameter module disconnected during copying process ? Switching off/on during copying process Prior to acknowledging the fault: ? Load the factory setting or the complete data record from the parameter module
